Specifications

  • MPN: 00.7618.185.000
  • Model ID: FD-RIV-E-E1
  • System: SRAM Rival AXS E1
  • Speed: 12-speed
  • Drivetrain configuration: 2x
  • Cable routing: Wireless
  • Communication protocol: AXS
  • Shift technology: Yaw, with auto trim
  • Mounting type: Braze-on (clamp sold separately, 31.8 mm or 34.9 mm)
  • Chainring compatibility: 46/33T, 48/35T, 50/37T
  • Chainstay angle: 61 to 66 degrees
  • Chainline: 45.0 mm
  • Chain technology: Road Flattop D1/E1
  • Battery: Not included, sold separately
  • Included: Front derailleur setup tool
  • Application: Road, gravel
  • Color: Black

FAQ

Is a battery included?

No. The AXS battery is sold separately. If you already run AXS you can share batteries across components, but a first AXS purchase needs one added.

What mount does this use?

This one is braze-on. It bolts to a tab on your frame. If your frame has no tab, SRAM offers clamps in 31.8 mm and 34.9 mm, sold separately.

Which chainring combinations work with it?

46/33T, 48/35T, and 50/37T. 50/37T is the largest combination it will handle. If you need a chainring larger than 50/37T, you need the RED E1 front derailleur instead.

What is Yaw and why does it matter?

Yaw rotates the cage as it moves outboard, keeping the cage plates parallel to the chain rather than angled into it. That is what removes chain rub in the cross gears without a trim lever. Auto trim handles the rest automatically.

Will it fit my frame?

It fits chainstay angles from 61 to 66 degrees and runs a 45 mm chainline. Check your frame's chainstay angle if you are unsure, since outside that range the cage will not sit correctly.

Does it come with a setup tool?

Yes, SRAM includes the front derailleur setup tool in the box, which sets the position for you. Final adjustment runs through the AXS app.

Best For

Riders building or repairing a 2x Rival AXS E1 road or gravel drivetrain Frames with a braze-on front derailleur tab, or riders willing to add a clamp Anyone who wants wireless front shifting without Force or RED money 46/33T, 48/35T, and 50/37T chainring setups
