Specifications
- Model: Scott Scale 910 Bike
- MPN: 425463
- Color: White
- Sizes: S, M, L, XL
- Discipline: Cross country and marathon
- Frame Material: Scale Carbon HMF, monocoque construction
- Frame Features: Adjustable head angle, Syncros Cable Integration System, Advanced Shock and Standing Damping System, UDH Interface
- Bottom Bracket Shell: BB92, 41x92mm
- Rear Axle: 12x148mm Boost, 55mm chainline
- Front Axle: 15x110mm Boost
- Headset Standard: ZS56/28.6 upper, ZS56/40 lower, plus or minus 0.6 degree head angle adjustment
- Fork Travel: 110mm
- Wheel Size: 29 inch
- Drivetrain: 1x12, SRAM Eagle 70 Transmission
- Brake Type: Hydraulic disc, 180mm front and 160mm rear rotors
- Seatpost Diameter: 31.6mm
- Approx Weight: 11.9kg (26.23lb), tubeless setup
- Max System Weight: 130kg, bike plus rider plus equipment
- Riding Condition: Scott condition 3, cross country and marathon
Build Specs
- Frame: Scale Carbon HMF, adjustable head angle, Syncros Cable Integration System, Advanced Shock and Standing Damping System, BB92, UDH Interface, 12x148mm with 55mm chainline, White
- Fork: FOX 32 Float Rhythm Grip, 110mm travel, 3-mode compression, rebound adjust, lockout, 15x110mm QR axle, 44mm offset, tapered steerer
- Remote: SCOTT RideLoc Technology suspension and dropper remote, 3 suspension modes
- Headset: Syncros and Acros Angle Adjust and Cable Routing HS System, plus or minus 0.6 degree head angle adjustment, ZS56/28.6 to ZS56/40 MTB
- Shifter: SRAM Eagle 70 Trigger, 12-speed
- Rear Derailleur: SRAM Eagle 70 Transmission, 12-speed
- Cassette: SRAM Eagle XS 1270 V2 Transmission, 10-52T, 12-speed
- Chain: SRAM CN Eagle 70 Transmission
- Crankset: SRAM Eagle 70 Transmission, DUB, 55mm chainline, 32T chainring, 170mm on S and M, 175mm on L and XL
- Chainguide: SCOTT custom
- Bottom Bracket: SRAM DUB PF92 MTB Wide, 41x92mm shell
- Brakes: Shimano MT401 hydraulic disc
- Brake Rotors: Shimano SM-RT10 Center Lock, 180mm front and 160mm rear
- Front Hub: Formula CL-811, 15x110mm
- Rear Hub: Formula CL-3248, 12x148mm
- Spokes: Stainless black 15G, 1.8mm
- Rims: Syncros X-30SE, 32H, 30mm inner width, tubeless ready
- Front Tire: Maxxis Rekon Race, 29x2.4 inch, 120TPI foldable bead, tubeless ready, EXO
- Rear Tire: Maxxis Rekon Race, 29x2.4 inch, 120TPI foldable bead, tubeless ready, EXO
- Saddle: Syncros Belcarra Regular 2.5
- Seatpost: Syncros Duncan Dropper, 31.6mm, 100mm travel on S, 130mm on M, 150mm on L and XL
- Handlebar: Syncros Alloy 6061, T shape flat, 9 degree sweep, 740mm
- Stem: Syncros DC 3.0, Syncros Cable Integration System, 0 degree rise, 6061 alloy, 31.8mm clamp, 1 1/8 inch, 50mm on S, 60mm on M, 70mm on L, 80mm on XL
- Grips: Syncros Performance XC lock-on
Sizing Guide
- S: Reach 418.5mm, stack 600.3mm, seat tube 390mm, standover 752mm, 100mm dropper, 50mm stem, 170mm cranks
- M: Reach 442.3mm, stack 604.9mm, seat tube 440mm, standover 781mm, 130mm dropper, 60mm stem, 170mm cranks
- L: Reach 463.6mm, stack 618.9mm, seat tube 480mm, standover 800mm, 150mm dropper, 70mm stem, 175mm cranks
- XL: Reach 491.2mm, stack 628.1mm, seat tube 530mm, standover 835.1mm, 150mm dropper, 80mm stem, 175mm cranks
Scott publishes sizing through its Smartfit system rather than a fixed height chart. Use the reach and standover figures as your starting point, and if you are between sizes, a professional fit at Dialed Cycling Lab is the best way to lock it in.
Geometry
Values shown in size order: S / M / L / XL. Head tube angle given at the plus 0.6 degree headset setting.
- Head Tube Angle: 67.9 degrees / 67.9 degrees / 67.9 degrees / 67.9 degrees
- Head Tube Length: 90.0mm / 95.0mm / 110.0mm / 120.0mm
- Top Tube (Horizontal): 575.0mm / 600.2mm / 626.0mm / 656.5mm
- Standover: 752.0mm / 781.0mm / 800.0mm / 835.1mm
- BB Offset: -62.0mm / -62.0mm / -62.0mm / -62.0mm
- BB Height: 313.0mm / 313.0mm / 313.0mm / 313.0mm
- Wheelbase: 1105.4mm / 1131.1mm / 1158.0mm / 1189.4mm
- Seat Tube Length: 390.0mm / 440.0mm / 480.0mm / 530.0mm
- Seat Tube Angle: 75.4 degrees / 75.4 degrees / 75.3 degrees / 75.3 degrees
- Chainstay: 425.0mm / 425.0mm / 425.0mm / 425.0mm
- Reach: 418.5mm / 442.3mm / 463.6mm / 491.2mm
- Stack: 600.3mm / 604.9mm / 618.9mm / 628.1mm
- Stem Length: 50.0mm / 60.0mm / 70.0mm / 80.0mm
- Trail: 105.0mm / 105.0mm / 105.0mm / 105.0mm
- Fork Length: 506.0mm / 506.0mm / 506.0mm / 506.0mm
- Max Seatpost Insertion: 160.0mm / 210.0mm / 250.0mm / 300.0mm
- Crank Length: 170.0mm / 170.0mm / 175.0mm / 175.0mm
FAQ
What is SRAM Eagle 70 Transmission and why does it matter on the Scale 910?
Eagle 70 Transmission is a 12-speed mechanical drivetrain that mounts directly to the frame through the UDH interface, with no separate derailleur hanger. The Scale 910 pairs it with a 10-52T cassette and a 32T chainring, so you get a wide climbing range from a single chainring.
How does the RideLoc remote work?
The SCOTT RideLoc lever on the bar controls three compression modes on the FOX 32 Float Rhythm fork, from fully open to locked out, and it also runs the Syncros Duncan dropper post. One lever, two jobs, so you can lock the fork for a climb and drop the saddle for the descent without moving your hands.
Can I adjust the head angle?
Yes. The Syncros and Acros angle adjust headset moves the head angle 0.6 degrees slacker or steeper by rotating the headset cups 180 degrees. Scott designed it so you do not need to cut cables or bleed brakes to make the change.
What sizes does it come in, and what is in stock?
The Scale 910 comes in S, M, L, and XL. This listing has size L in stock and ready to ride now. The other sizes are available for special order, so reach out to the shop and we will get your size on the way. Frame size depends on your inseam, torso, and reach preference rather than height alone, so get in touch if you sit between two sizes and we can talk it through.
Best For
Cross country racers and marathon riders who want a carbon race hardtail with a modern drivetrain and a cockpit that stays out of the way. The Scale 910 suits the rider lining up for local XC races, long days on fast singletrack, and anyone who wants the efficiency of a hardtail with 110mm of travel up front and a dropper post for the descents.
