Specifications

  • Wheel Size: 700c
  • Rim Depth: 50mm
  • Rim Internal Width: 23mm
  • Rim External Width: 29mm
  • Rim Construction: Hookless/Tubeless Straight Side (TSS)
  • Rim Profile: Symmetrical
  • Tire Compatibility: Tubeless tires only
  • Recommended Tire Width: 28 to 40mm
  • Max Tire Pressure: 73 psi (5.0 bar)
  • Rim Finish: UD fiber with adhesive decals
  • Hubs: Zipp 76/176, 36 points of engagement
  • Bearings: Stainless steel cartridge
  • Spokes: Sapim CX-Sprint, 2-cross, 20 front and 24 rear
  • Nipples: Aluminum
  • Brake Interface: Disc, Center Lock
  • Axle: Front 12x100mm thru axle, rear 12x142mm thru axle
  • Rear Driver Body: SRAM XDR
  • Weight: Front 713g, rear 872g, 1585g per pair (Zipp estimate with 12mm thru axles, XDR driver, tape and valves installed)
  • Max System Weight: 115kg (253lb) rider plus gear
  • Warranty: Zipp Lifetime Warranty and Crash Replacement policy
  • MPN: Front 00.1918.802.000, Rear SRAM XDR 00.1918.803.001

FAQ

Can I run inner tubes or regular clincher tires on the Zipp 404 S?

No. The 404 S uses Zipp's Hookless/Tubeless Straight Side (TSS) rim, and Zipp lists it for tubeless tires only. Make sure any tire you choose is approved for hookless rims.

What tire width works best on the Zipp 404 S?

Zipp pairs the 23mm internal rim width with 28 to 40mm tires. The maximum tire pressure is 73 psi (5.0 bar).

Are the front and rear Zipp 404 S wheels sold together?

No. Each wheel is its own option on this page, so you can buy the front, the rear with a SRAM XDR driver, or both to make a pair.

What brake rotors and axles does the Zipp 404 S use?

Center Lock disc rotors on 12mm thru axles: 12x100mm on the front wheel and 12x142mm on the rear.

Best For

The Zipp 404 S is best for road racers, criterium riders and fast group riders on disc-brake road bikes who want a 50mm carbon wheel that is quick on flat and rolling roads and steady enough for windy days.
