Is the Syncros XC 2.0 Stem the right choice for your XC race bike or downcountry build?

The Syncros XC 2.0 Stem is built for cross-country racers and downcountry riders who want a low, aggressive handlebar position without overhauling their entire cockpit. Designed alongside the SCOTT Spark RC, the XC 2.0 uses a low stack height and progressively-tuned negative rise across the length range, so the stack stays consistent at any size while the reach changes to match your fit. The forged and machined AL6061 aluminum body delivers the strength and stiffness you want under hard sprints and steep descents without the weight penalty of overbuilt alternatives.

A closed-type face plate gives the cockpit a clean, integrated look and works with any 31.8mm handlebar, and corrosion-resistant Torx T25 steel bolts hold up to long-term sweat and weather exposure. The stem ships complete with its top cap and bolt, so the install is plug-and-play. Available in 50, 60, 70, 80, and 90mm lengths, each with its own engineered angle to maintain the stack across the size range.

All the specs

Material
Forged and machined AL6061 aluminum
Clamp Diameter
31.8mm
Steerer Diameter
1 1/8 inch
Available Lengths
50, 60, 70, 80, 90mm
Angle by Length
50mm -14 degrees, 60mm -12 degrees, 70mm -10 degrees, 80mm -9 degrees, 90mm -8 degrees
Face Plate
Closed-type for integrated design
Hardware
Corrosion-resistant Torx T25 steel bolts
Weight
Approximately 160g (varies by length)
Color
Black
Designed For
SCOTT Spark RC and modern XC bikes with 1 1/8 inch steerer
Range of Use
Cross-country, downcountry, MTB

In the box

  • Stem top cap and bolt

FAQ

Good questions

Get to know Syncros

There's more to Syncros than this one product. Our Syncros page has the full Syncros lineup we carry and more about the brand.

Visit the Syncros page →
Why does each stem length have a different angle?

Each length is engineered with a specific negative rise so the stack height stays the same across all sizes. 50mm is -14 degrees, 60mm is -12 degrees, 70mm is -10 degrees, 80mm is -9 degrees, and 90mm is -8 degrees. Changing length changes reach only, not bar height.

Will it fit any mountain bike with a 1 1/8 inch steerer?

The XC 2.0 was designed for the SCOTT Spark RC and integrates cleanly with that frame's headset cable routing. It will also fit any bike with a standard 1 1/8 inch steerer tube. If your frame uses cable routing through the headset like a Trek with Knock Block, check fitment before ordering.

Will my 31.8mm handlebar work with this stem?

Yes. The clamp diameter is 31.8mm, which is the standard mountain bike handlebar size and compatible with most current XC and trail bars.

What is included in the box?

The stem ships with its integrated top cap and bolt, plus the Torx T25 face plate bolts. You only need a Torx T25 wrench and a fresh stem for the install.
