ENVE Mog Frameset - Topo Green | 54cm

Hidden hoses and wires are the name of the game when it comes to the modern bicycle and the expectations of the rider. ENVE's IN-Route System is designed to hide hoses and wires from the wind, improving the bike's aero performance with a practical and user-friendly solution. This doesn't come at the expense of limiting drivetrain options - The Road IN-Route fork is compatible with most drivetrain brands, models, and configurations on the market.

Enve Mog Frameset (Frame and Fork) – Topo Green | 54cm

Full of capability and overflowing with versatility, the MOG delivers a world of possibilities ranging from adventure to race, and everything between. With abundant tire clearance, storage solutions, and performance geometry, the MOG has it all, and more.

Ride Tuned

Details:

• Elite off-road machine for gravel racing, riding, and exploring
• Frame weight: 950 grams (56cm, painted, no hardware)
• Optimized for modern gravel handling with a road-like geometry
• Features fully integrated internal wire, hose, and dropper routing
• Includes two in-frame downtube storage bags to hold spares, tools, and more
• Designed for 700c x 40-44mm tires with a max clearance of 50mm

Compatibility:

• Compatible with fenders and 1x drivetrain dropper posts
• 2X Shimano GRX double cranks (47mm chainline).
• All currently available Shimano GRX double chainring combinations are compatible.
• Using a Shimano GRX front derailleur limits the tire size to a max of 47mm according to Shimano’s spec.
• 2X SRAM WIDE double cranks (47.5mm chainline).
• All currently available SRAM WIDE double chainring combinations are compatible.
• Using a SRAM WIDE front derailleur limits the tire size to a max of 45mm according to SRAM’s spec.
• *Standard road double cranks WILL NOT fit.
• 1X Max 44T for 44.5-45.5 chainline (SRAM 1x Cranks w/ typical aftermarket direct mount chainrings.
• 1X Max 50T for 47+ Chainline (Shimano GRX, SRAM 1X WIDE).
• 1x Ekar has a 45.5-46.5 chainline and cranks that are offered with 38-44T options will fit MOG.
• *Older SRAM Force 1 (or similar) 5-bolt cranks will NOT clear with the stock bolt spacers on the backside of the chaining spider. These cranks are compatible if the stock ring and spider is swapped for a direct-mount ring.

Specs:

• Head Tube Diameter – 1 1/8in
• Headset Included – ENVE Integrated IS52/IS52 Internal Drop-In
• Bottom Bracket Type – T47 inboard bearing
• Cable Routing – Internal
• Front Derailleur Mount – Braze-on
• Brake Type – flat-mount, disc
• Handlebar – ENVE Gravel, ENVE SES AR, ENVE SES AR One-Piece, or ENVE Compact (not included)
• Stem – In-Route Aero or In-Route High Rise Stem (not included)
• Seatpost – ENVE G series dropper or ENVE Seatpost (not included)
• Seatpost Diameter – 27.2mm
• Seat Collar – 12 x 100mm Thru-axle
• Front Axle – 12 x 142mm Thru-axle
• Rear Axle – 700 x 35 – 44mm
• Tire Clearance – 700 x 50c
• Extras – Downtube protector, 2 Cargo Bay storage bags
• Includes – Universal Derailleur Hanger
• Claimed Weight[size 56] 950g
• Activity – Gravel
• Manufacturer Warranty – 5 years

MPN: 100-5004-554
